Angel 4 MKII Power Amplifier
The Angel-4 MKII uses the same design and principles as the Angel-6, scaled down for more domestic compatibility.
Building on the success of the original Angel-4, the Angel-4 Mk II is packed full of substantial upgrades. From the outside there’s no visible sign that anything has changed, but it’s what’s on the inside that counts when it comes to making music!
What Does This Mean For Your Music?
– An incredibly natural sound for instruments and vocals
– Fine detail resolution and massive dynamic range
– Awesome grip on timing and rhythm
– An immersive, believable musical experience
What Makes For The Astonishing Musical Performance Of The Angel 4 MKII?
The Angel-4 Mk II uses a full 3-island power supply like the flagship Angel-6 amplifier. This requires 3 times as many capacitors as a conventional amplifier supply, but the effort is repaid with even more layers of transparency and detail.
The upgrade has more than tripled the capacitance compared to the original Angel-4 power supply. This really is the high-Cap version of the Angel-4! Not only has the capacitance increased drastically, but we’ve also improved the quality of the supply to each amplifier module by lowering the supply impedance.
Retaining a single-box design allows us to keep the impedance of the power supply as low as possible, and we’ve further optimised the supply routing and reduced track lengths to gain even more benefit from the capacitor upgrades. This all results in better dynamics and the amplifier has tighter control of the loudspeaker.
The improvements that these upgrades make to the sound of the Angel-4 Mk II are wide-ranging: instruments sound more natural, the flow and rhythm of the music are more effortless and addictive; basslines have more texture and are full of character; percussion is, well, more percussive and realistic; and individual threads in the music are easier to follow, having more space and soundstage, without sounding at all analytical. In short, it’s even more musical.
For existing Angel-4 customers, your Angel-4 can be fully upgraded to an Angel-4 Mk II by a return-to-factory upgrade service. Email us at support@mooramps.co.uk for further details or contact us through our website www.mooramps.co.uk
Specifications
Output Power
- 75W RMS per channel into 8 ohms
- 150W RMS per channel into 4 ohms
Distortion
( with typical loudspeaker load )
- THD: < 0.01%
- IMD: < 0.01%
Loudspeaker Outputs
- Nominal: 4 ohm to 16 ohm
- Connections: Wired, Spade or 4mm plug
Inputs
RCA (phono) inputs:
- 1V rms for full output
- Input Impedance 15k ohm
Frequency Response
5Hz to 50kHz +/- 1dB
Protections
- Short Circuit or Overload: +/-15A max
- Overtemperature: +55C
- Undertemperature: +5C
Measurements
Amplifier dimensions:
- Width 430mm x Depth 340mm x Height 120mm
- Weight 18kg
Packaged dimensions:
- Width 490mm x Depth 420mm x Height 170mm
- Weight 18kg
Mains Power
- IEC inlet cable for 230V AC 50Hz mains
- Optional 115V AC 60Hz version available
Power Consumption:
- Maximum 650VA
- Idle 50VA
- Standby < 0.5W
£8000
